Product Summary
The 74HC154 is a 4-to-16 line decoder/demultiplexer. The 74HC154 is a high-speed Si-gate CMOS device and is pin compatible with low power Schottky TTL(LSTTL). It is specified in compliance with JEDEC standard no. 7A. The 74HC154 accepts four active HIGH binary address inputs and provide 16 mutually exclusive active LOW outputs. The 2-input enable gate of the 74HC154 can be used to strobe the decoder to eliminate the normal decoding “glitches” on the outputs, or it can be used for the expansion of the decoder.
Parametrics
74HC154 absolute maximum ratings: (1)supply voltage: -0.5V to +7.0V; (2)input diode current: ±20mA; (3)output diode current: ±20mA; (4)output source or sink current: ±25mA; (5)VCC or GND current: ±50mA; (6)storage temperature: -65 to +150℃; (7)power dissipation: 300mW.
Features
74HC154 features: (1)16-line demultiplexing capability; (2)Decodes 4 binary-coded inputs into one of 16 mutually exclusive outputs; (3)2-input enable gate for strobing or expansion; (4)Output capability: standard; (5)ICC category: MSI.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 74HC154 |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
 |
74HC154BQ,115 |
|
IC 4:16 DECODER/DEMUX 24DHVQFN |
Data Sheet |
Negotiable |
|
||||||||||||
|
74HC154BQ,118 |
NXP Semiconductors |
Encoders, Decoders, Multiplexers & Demultiplexers Decoder/Demultiplexe Single 4-to-16 24Pin |
Data Sheet |
|
|
||||||||||||
 |
74HC154BQ-G |
NXP Semiconductors |
Encoders, Decoders, Multiplexers & Demultiplexers 5V 4-TO-16 LINE DECDR/DEMUX |
Data Sheet |
Negotiable |
|
||||||||||||
 |
74HC154D |
NXP Semiconductors |
Encoders, Decoders, Multiplexers & Demultiplexers 4-16 LINE DCOD/DMUX |
Data Sheet |
Negotiable |
|
||||||||||||
|
74HC154D,652 |
NXP Semiconductors |
Encoders, Decoders, Multiplexers & Demultiplexers 4-16 LINE DCOD/DMUX |
Data Sheet |
|
|
||||||||||||
|
74HC154D,653 |
NXP Semiconductors |
Encoders, Decoders, Multiplexers & Demultiplexers 4-16 DECODER/DEMUX |
Data Sheet |
|
|
||||||||||||
|
74HC154DB,112 |
NXP Semiconductors |
Encoders, Decoders, Multiplexers & Demultiplexers 4-16 DECODER/DEMUX |
Data Sheet |
|
|
||||||||||||
