Product Summary

The XC3S250E-4FT256C is a Field-Programmable Gate Array (FPGA). It is specifically designed to meet the needs of high volume, cost-sensitive consumer electronic applications.

Parametrics

XC3S250E-4FT256C absolute maximum ratings: (1)VCCINT, Internal supply voltage: 鈥?.5 to 1.32 V; (2)VCCAUX, Auxiliary supply voltage: 鈥?.5 to 3.00 V; (3)VCCO, Output driver supply voltage: 鈥?.5 to 3.75 V; (4)VREF, Input reference voltage: 鈥?.5 to VCCO+0.5 V; (5)TJ, Junction temperature: 125鈩?max; (6)TSTG, Storage temperature: 鈥?5 to 150鈩?

Features

XC3S250E-4FT256C features: (1)Very low cost, high-performance logic solution for high-volume, consumer-oriented applications; (2)Proven advanced 90-nanometer process technology; (3)Multi-voltage, multi-standard SelectIO interface pins; (4)Abundant, flexible logic resources; (5)Hierarchical SelectRAM memory architecture; (6)Up to eight Digital Clock Managers (DCMs); (7)Eight global clocks and eight clocks for each half of device, plus abundant low-skew routing; (8)Configuration interface to industry-standard PROMs; (9)Complete Xilinx ISE Web PACK development system support; (10)MicroBlaze PicoBlaze embedded processor cores; (11)Fully compliant 32-/64-bit 33/66 MHz PCI support; (12)Low-cost QFP and BGA packaging options.

Diagrams

<IMG src="http://www.seekic.com/uploadfile/ic-mfg/2012530203556209.jpg" border=0>

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
XC3S250E-4FT256C
XC3S250E-4FT256C

Other


Data Sheet

Negotiable
