Product Summary
The SAB80C537-16-N is a high-end microcontroller in the Siemens SAB 8051 8-bit microcontroller. The SAB80C537-16-N is based on the well-known industry standard 8051 architecture.
Parametrics
SAB80C537-16-N absolute maximum ratings: (1)Ambient temperature under bias:0℃ to 70℃; (2)Storage temperature:-65℃ to 150℃ ; (3)Voltage on VCC pins with respect to ground (VSS):-0.5V to 6.5V; (4)Voltage on any pin with respect to ground:-0.5V to VCC+0.5V ; (5)Input current on any pin during overload condition:-10mA to +10mA; (6)Absolute sum of all input currents during overload condition:|100mA| ; (7)Power dissipation:2 W.
Features
SAB80C537-16-N features: (1)ROMIess version also available; (2)256 byte on-chip RAM; (3)256 directly addressable bits; (4)1 microsecond instruction cycle at 12-MHz oscillator frequency; (5)64 of 111 instructions are executed in one instruction cycle; (6)External program and data memory expandable up to 64 Kbyte each; (7)8-bit A/D converter; (8)Eight fast 16-bit compare registers; (9)Arithmetic unit for division, multiplication, shift and normalize operations; (10)Eight datapointers instead of one for indirect addressing of program and external data memory.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||
---|---|---|---|---|---|---|---|---|---|---|
SAB80C537-16-NT40/85 |
Other |
Data Sheet |
Negotiable |
|
||||||
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||
SAB8032 |
Other |
Data Sheet |
Negotiable |
|
||||||
SAB8032A |
Other |
Data Sheet |
Negotiable |
|
||||||
SAB80515 |
Other |
Data Sheet |
Negotiable |
|
||||||
SAB8085AH-2-P |
Other |
Data Sheet |
Negotiable |
|
||||||
SAB8086 |
Other |
Data Sheet |
Negotiable |
|
||||||
SAB8088 |
Other |
Data Sheet |
Negotiable |
|
