Product Summary

The XC2S300E-7PQG208C is a Field-Programmable Gate Array. It gives users high performance, abundant logic resources, and a rich feature set, all at an exceptionally low price. The XC2S300E-7PQG208C offers densities ranging from 50,000 to 600,000 system gates. System performance is supported beyond 200 MHz.

Parametrics

XC2S300E-7PQG208C absolute maximum ratings: (1)VCCINT, Supply voltage relative to GND: 鈥?.5 to 2.0V; (2)VCCO, Supply voltage relative to GND: 鈥?.5 to 4.0V; (3)VREF, Input reference voltage: 鈥?.5 to 4.0V; (4)VIN, Input voltage relative to GND: 鈥?.5 to 4.0V; (5)VTS, Voltage applied to 3-state output: 鈥?.5 to 4.0V; (6)TSTG, Storage temperature (ambient): 鈥?5 to +150鈩? (7)TJ, Junction temperature: +125鈩?

Features

XC2S300E-7PQG208C features: (1)second generation ASIC replacement technology; (2)Fully 3.3V PCI compliant to 64 bits at 66 MHz and CardBus compliant; (3)Lowpower segmented routing architecture; (4)Dedicated carry logic for highspeed arithmetic; (5)Efficient multiplier support; (6)Cascade chain for wideinput functions; (7)Abundant registers/latches with enable, set, reset; (8)Four dedicated DLLs for advanced clock control.

Diagrams

<IMG src="http://www.seekic.com/uploadfile/ic-mfg/201253024844452.jpg" border=0>
